Brand/Model
part #
Description/Notes Price

ORDER

Addison 2 & L2

laser printed High quality stiff paper or laminated plastic

there are 7 color combinations, be sure and specify color number

$25 or $35

Admiral 7"
TV model 19A12

channel selector dial scale
*NOTE please read  before ordering  Vinyl overlay with adhesive backing


$25.00


Aetna (Walgreen's)

laminated plastic

For models 604, 606 or 653

$40.00

Air Chief
R-1661-A
laminated plastic

measures 6- 13/16" diameter

$45.00


Allied Radio

 > see Knight

All
American Mohawk
"Navaho"

 Silver foil

NOTE: this is an adhesive backed, foil overlay that's to be applied over the original disk

$45.00

Air Castle
5000

laminated plastic

NOTE: the original was slightly domed, my repro is flat. It can be trimmed to fit under the bezel or left as-is & mounted behind the bezel.

$45.00

Airline 04BR-729A

laminated plastic


$35.00

Airline 74BR1501

Transparency

(specify style)


$35.00

Arvin
402

 Gold Foil with adhesive backing

$35.00


Arvin
444

 Gold Foil with adhesive backing

$35.00


Return

Arvin 532

laminated plastic or  Gold foil

$35 or $45

Arvin
664 series

 Gold or Silver foil - specify

there are a number of Arvin  models using this same scale configuration in various colors schemes. Let me know if you desire a color other than those shown.

$40.00


Arvin pt#
A29-16840

laminated plastic or laser printed High quality stiff paper (specify)

measures; 2, 3/8 x 3, 1/8"

$25 or $35


Arvin pt#
A29-17269

 Gold or Silver foil

measures 4, 1/8 x 4, 1/8"

$40.00

Arvin 617
laminated plastic $45.00

Arvin 927
(Rhythm Queen)
laminated plastic $55.00

Atwater-Kent
70, 75, 76

laminated plastic $35.00

Atwater-Kent
80, 84, 92

laminated plastic $35.00
Automatic Radio "Tom Thumb"
models 950 - 955

Gold or Silver foil

$35.00

Return                                  >> B <<

Balkeit 41A
pt# 36938 I make this dial in two styles, 1 with colors filled in, the other with colored back-side with fewer colors (like the original.) Be sure and look at enlarged images.

laminated plastic

measures 5" dia.

$35 or $45.00
Belmont 6D110
laminated plastic $35.00
Belmont  models 121, 628 & 6D111
laminated plastic

(specify color)
(1, 2 or 3)

$35.00
Belmont 519
Transparency
part numbers = 5257 & 1125758
$35.00
Belmont 529
Transparency
part number = 113-326
$35.00

Return                                 >> C <<

Clarion C100
Gold foil

This beautiful dial was meticulously re-created to replicate the properties of the original as close as possible.
$45.00
Clarion
laminated plastic

measures 4 - 7/8" dia.
$40.00
Colonial Radio "New World Globe"
laminated plastic $40.00
Colonial Radio 653
laminated plastic $30.00
Colonial Radio
(part # R10775)
laminated plastic

measures 4.25" square
$40.00
Coronado
laminated plastic

measures 5 - 15/16" dia.
$40.00
Crosley
(G-3634)
laminated plastic or laser printed High quality stiff paper (specify)

measures; 4.75 x 4, 5/8"

$25 or $35
Crosley 56T series
 laminated plastic  or Gold or Silver foil
Pt# B136725
$35 or $45
Crosley 165 & 167
laminated plastic

available in green or amber - SPECIFY

$30.00

Return                               >> D <<

Dalbar of Dallas
laminated plastic or laser printed High quality stiff paper (specify)

colorful sunburst dial

$25 or $35
Detrola 212
Gold or Silver foil

part # 5195

$40.00
Detrola 4-D
laminated plastic $30.00
Detrola
pt #3374 laminated plastic $45.00
Detrola
pt #3374-C laminated plastic $45.00

     Return                            >> E <<

Emerson pt# 5FZ-755-A
laminated plastic,


measures 4-7/8 x 4-3/16"



$40.00

Emerson pt# 3RZ477
laminated plastic,


measures 4-7/8 x 4-3/16"



$40.00

Emerson pt# 4FZ596
laminated plastic,

large opaque scale,
measures 6 7/16 x 6"



$40.00

Emerson AU-190
laminated plastic


measures 4 7/16 x 2 3/4"

$40.00

Emerson AX-214
laminated plastic also used in other models

measures 2 11/16 x  3 1/8"

$35.00
Emerson BN-206
(and other models)
Gold foil with all the background detail

this dial scale is also used on other models.

measures; 2- 15/16 x 4-3/4"

$45.00
Emerson CR-261
laminated plastic  or Gold foil


measures 3 5/16 x 3"

$35 or $45

Emerson CH-256 "Strad"
laminated plastic  or Gold foil


measures 2 13/16 x 3 1/16"

$35 or $45

Emerson
CY-288
"Big Strad"
laminated plastic


measures 4 1/4 x 3 5/8"

$35.00

Emerson DW-330B
pt # 7WD-104

laminated plastic  or Gold foil

Gold foil with all the background detail

measures 4 7/16 x " 4 1/2

$35 or $45
Emerson 540A
laminated plastic

measures 2 x 3"

$30.00

Return                                 >> F <<

Fairbanks- Morse
part #5905  laminated plastic

measures 6.25" dia.



$45.00
Fairbanks- Morse
part #58__?  laminated plastic

only minor differences from the above version

measures 6.25" dia.

$45.00
FADA 711
laminated plastic $35.00
Firestone
> see Air Chief






FADA 1000
laminated plastic $35.00


Return                              >> G <<

Graybar 678 Same as Radiola 48 dial scale
G&F "Searchlight"
or "Spy-Glass"
laminated plastic

flat media, not formed like the original

$45.00

General Electric
G=-E "Commentator"

Transparency, laminated plastic

small , measures 2- 3/8 x 2- 3/4"

$35.00

General Electric
H-610
and other H series models

Transparency, laminated plastic
pt# M15J-655

small , measures  3- 3/8 x 3- 3/4"

$35.00

G-E M-42
laminated plastic may also be used on other models $30.00

G-E (General Electric T-41 Same as Radiola 48 dial scale
Gilbert model unknown
transparent overlay also used on other brands $30.00

Grunow
Part # 39730-2

laminated plastic

measures; 6-7/8" square

$45.00

Return                                   >> H <<

Hallicrafters model unknown Transparent overlay also used on other brands
SAME AS THE ABOVE (Gilbert) DIAL

Howard
H-68, 218
laminated plastic

Pt# 4089

measures 6- 7/16" dia.

$45.00

HMV 475


Translucent, laminated $45.00

Return                                  >> I <<

Imperial > see Balkeit

International radio > See Kadette:

Return                                 >> K <<

Kadette "Classic" models K-10 -16 Gold foil $45.00
Kadette "Topper" model L-25, 29
Transparency  with gold lettering $35.00
Kadette model A&B
laminated plastic $35.00
Kitchenaire (Radio Craftsmen)

Transparency  underlay If you still have the original glass with worn off graphics, you can simply clean the glass and mount my transparency under it. If your glass is broken you can fabricate a new one with a piece of acrylic or other clear plastic.

$30.00
Knight
laminated plastic or Gold or Silver foil

$35 or $45
Knight 9
Large gold foil dial

measures 11- 1/16 x 4"

$45
Knight
unknown
 laminated plastic

measures 6- 7/16" dia.

 this dial is also used on other radio brands

$45

Return                               >> L <<

Lafayette
 this dial is also used on other radio brands

laminated plastic or Gold or Silver foil

$35 or $45
Lafayette model AS6
 pt# 36978 laminated plastic

this dial is also used on other radio brands

small, measures 2-9/16" dia.

$35.00
Lyric 546T
 laminated plastic or Gold or Silver foil $35 or $45


Return                              >> M <<

Marconi

style 1

style 2

 laminated plastic

measures 8-5/16 x 8- 3/8

the original text was on glass, mine is made to be mounted behind glass and pointer to the metal back plate. The original glass should be cleaned of any remaining text. If original glass is broken, I can  make a replacement of clear acrylic.

$45.00

  $60.00
clear acrylic plate with two holes drilled

Majestic Charlie
McCarthy Radio

Translucent Scale

Flat transparency

specify style 1 or 2

$35.00
Majestic 5T, 5TO
amber phenolic with overlay $45.00
Majestic model 25

laminated plastic

 measures 5-11/16" at the widest part

  $35.00
Majestic model 59

laminated plastic

measures 3.5" wide

  $35.00
Majestic models
551 and 651

Dial scale done on
Gold foil
<< click on image to view both versions
beautiful reproduction unlike what others offer, I leave all the background detail in place
$45.00
551
$45.00
561
 above laser printed on heavy paper for cost savings $30.00
551
$30.00
561
Maestro
laminated plastic $45.00
McMurdo-Silver 15-17
laminated plastic, beautifully re-mastered and very colorful $70.00
Mohawk see All American Mohawk
Monarch
laminated plastic, measures;4,3/16" diameter

(may fit other generic looking cathedrals)

$35.00

Monarch
model unknown

 laminated plastic
measures 4- 3/8 x 3- 1/2"
Available in 2 colors



$35.00
Motorola S-10 "Lazy Boy"
laminated plastic

Available in green or tan SPECIFY COLOR

$35.00
Motorola
51A & 52

Dial Scale replica

Gold  foil

$45.00
Musicaire
model unknown

 plastic laminated

small dial, about 2.3"  wide, for mini-cathedral

$35.00
Olympic
7-421W


Part # DL-1267 printed on gold foil with paper backing like the original $45.00

Return                              >> P <<

Packard Bell
551


laser printed on Vinyl overlay or paper with adhesive backing to apply over clear acrylic media $35.00
paper
$45.00
vinyl
Packard Bell
pt# 38032


laminated plastic $35.00
Packard Bell
Unknown
laminated plastic $35.00
Peter-Pan
laminated plastic

measures; 3-1/8" diameter

$35.00
Peter-Pan-4
laminated plastic

measures; 2.25 x 2.5"

$25.00
Philco
20 & 21
Dial scale laminated plastic

 measures; 4- 1/4" at the widest part

$35.00
Philco
70 & 90
Dial scale laminated plastic

 measures; 5-1/4" at the widest point



$35.00
Philco 650
transparent overlay, to use over original dial media

 measures; 6- 3/8" diameter

$35.00
Philco Dial
part #27-5100

laminated plastic

 measures; 1- 15/16 x 2-3/4"

$35.00
Philco Dial
model 19 0r 89
part #27-5001

dial strip approx. 1 x 8"

laminated plastic

$35.00
Philco Dial
part #27-5107

large, 8" diameter

laminated plastic

$65.00
Philco Dial
part #27-5168

small , measures approx. 3 x 3"

laminated plastic

$35.00
Philco Dial
part #27-5197

small , measures approx. 3.8 x 3.8"

laminated plastic

$35.00
Philco Dial
part #27-5280

small , measures approx. 3.5 x 3.5"

laminated plastic

$35.00
Philco Dial
part #27-5211

 large, 9- 3/16" diameter

$65.00
Philco Dial
part #27-5667

Laser printed High quality stiff paper

7.5 x 4.5" for model 41-258

$35.00



Philco Dial
part #27-5517

Gold foil

 measures 3- 15/16 x 4"

$45.00

Pilot 3" television
TV-37

Dial Scale replica

paper (just like the original), cut & trimmed with self adhesive backing

$30.00

Return

Pla-Pal
Dial Scale pair, includes the volume and tuning dial scale

laminated plastic
$40.00
Plymouth
also used on other brands

Gold or Silver foil - specify

$40.00

Return                             >> R <<

Radiola AR-810 & AR-812
Super-Het paper dial overlay fits the Radiola 24, AR-812 Super-heterodyne & Super VIII console plus some Brunswick & Victor models using the same tuner cardstock paper, cut cut trimmed and ready to install $25.00

(pair)

Radiola 16, 17,
18 & 60

dial scale band that goes around the tuning drum

laminated plastic
 or
Gold foil

$20.00
or
$25.00
original but worn (see image)

original

$25.00


1 only
Radiola 20 dial overlays


matt paper made to look like original. Pair, left & right dial paper replica $30.00
has some pencil marks (they were made to be marked)

original pair

$40.00

1 only

Radiola 33


laminated plastic

replica

$30.00
for those of you want to remain original, has some wear and a bit blemished

original

$30.00

1 only




1 only
Radiola 42 & 48
laminated plastic $40.00
Radiola 44

 original dial scale w/cut-out numbers & graticules for lens projection.
This dial is the same as used on Radiola 46 and other models. Measure to be sure, this one measures 7.75" (length)
$40.00
1 only
RCA 27410
laminated plastic



$40.00
RCA model 4X, 4X3 & 4X4
laminated plastic RCA
part # 27454
$35.00
RCA model 55X

 Pt# 29272-1

measures approx. 3.25 x 4.5"

Silver or Gold foil $45.00
RCA pt# 27418

laminated plastic

  $35.00
RCA pt# 27427

laminated plastic

  $35.00
RCA model 4T

laminated plastic

  $30.00
RCA model 100, 101, 103& 301
laminated plastic $30.00
RCA model 120
part# 280146 mounting collar not included

 laminated plastic

$30.00
RCA model 120
part# 280146, original with mounting hub $40.00
(1 only)

Return

RCA Victor R-7
laminated plastic $35.00
RCA Victor R-14, 15 & RE-17 Same as Radiola 48 dial scale
RCA Victor
RE-45

laminated plastic
For models R-32, R-35, R-39, R052, RE-45,
RE-57 & RE-75
$45.00

Return                              >> S <<

Sears

See Silvertone





Sentinel All Wave

laminated plastic
pt # 46324

with backlit color background just like original

$45.00

Scott All
Wave

laminated plastic
All Wave 12 tube (dual dial)

pair (left & right dials)

$45.00

Setchell Carlson
416 & 427 "Frog"

laminated plastic specify style (1,2 or3) $35.00

Setchell Carlson 58A
"Jet"

laminated plastic $35.00

Silvertone 1923

laminated plastic specify choice;  1or 2


dial # R12356

$35.00

Silvertone 1981

laminated plastic $45.00

Silvertone

 part #5952
laminated plastic

measures: 6-7/8 x 5-7/8"

$40.00

Silvertone 6106

 Gold or Silver foil - specify

dial # C19225
$45.00

Sonora WEU-240/262

 Laser printed on high quality  stiff paper $30.00

Coming Soon Sparton "Polo Club"



 Sparton

laminated plastic replica Pt# A-4584 used on model 737 and likely other models

measures 10.25" (length)

$30.00

Sparton 517

laminated plastic
part # B-7001-1
$40.00

Sparton 537

laminated plastic
part # C-2806 with is almost identical to C-2804
$45.00

Sparton 538

laminated plastic

6 1/8" diameter

$45.00

Sparton 570M

gold foil $45.00

Sparton 617

pt# C-2827

Laminated plastic



$45.00

Sparton 766

laminated plastic $45.00

Sparton
C-2810

laminated plastic

Sparton part #
C-2810

$45.00

Return

Sparton
C-3011

laminated plastic

COMING SOON

-

Sparton
C-3039

laminated plastic

Sparton part #
C-
3039

$45.00

Sparton
S-154D

laminated plastic

Sparton part #
S-154D

$40.00

Stewart-Warner
117007

3 band dial scale for unknown model. It can be size to fit your specifications up to 11" in width.

laminated plastic
$45.00

Stewart-Warner


BO6164

7 band dial scale for unknown model can be size to fit your specifications up to 11" in width.

laminated plastic
$45.00

Stewart-Warner 160169

2 band slide-rule dial  S-W pt# 160169
on gold foil

measures are; 3- 3/4 x 1-7/8"

$45.00

Stewart-Warner

2 band, clock style For O1-521, O3-5E1, R-5421 and others
see sample images and choose the style that matches your radio as close as possible. Pay particular attention to the bottom scale
 gold foil

BE SURE YOUR INDICATE STYLE NUMBER WHEN ORDERING

$45.00

Stewart-Warner
"Varsity"

laminated plastic $30.00

Stromberg-Carlson 350

laminated plastic

part# P-29047

measures 8-3/8 x 7-1/8

$45.00

Stromberg-Carlson 1110

laminated plastic

measures 2.5 x 5.25"

$35.00

Stromberg-Carlson 1121

laminated plastic

part# P122006

$45.00

Return                              >> T <<

Travel-Aire
model 431

 laminated plastic
measures 4- 3/8 x 3- 1/2"
Available in 2 colors



$35.00
Tom Thumb   See Automatic Radio

Trav-ler

unknown cathedral laminated plastic   $35.00

Trav-ler

for models 5028 & 5029 Gold or Silver foil & style choice Gold or Silver foil - specify $40.00

Trav-ler
5054/5055

Gold or Silver foil - and choice background color Gold or Silver foil - specify $40.00

 Truetone

 laminated plastic 2 styles, choose when order is placed $35.00

 Truetone

pt# 4931 laminated plastic   $45.00

 Truetone

for model D723 (and likely others) laminated plastic   $45.00

Return                            >> U <<

Unknown

laminated plastic
Pt# 66198

Large, 9.25 x 3-5/16"



Unknown

laminated plastic

Small, 3-1/8" dia.



                                      >> W <<

Wards,  Montgomery-Wards   See Airline

Western Air Patrol

laminated plastic
Pt# W3-WA?

small, 2-5/16" dia



  $35.00



Westinghouse
WR-4
laminated plastic Same as Radiola
48 dial scale




>> Z <<

Zaney Gill



"Vitatone"  dial scale laminated plastic $35.00

  Zenith Dial scales

 If the scale you are seeking is not listed, contact me, I may still be able to help.



Return





































  • Laminated plastic - most durable These are printed on a high quality, special paper and sealed in dual sided plastic laminate which can be back lighted.

  •

  • Color backside - the reverse side has the scale color. The colors are only present when illuminated from the back side (like the original).

  •

  • Gold or Silver foil - least durable as the foil is easy to scratch or dent (same goes for original foil dial scales). The scale is done on a laser printer and usually mounted to stiff paper like was the original. Some have adhesive backing and will be identified as a sticker. Be aware that many foil dials were embossed (stamped) which is a process I cannot do.

  •

  • Transparency (or translucent) - these are printed on clear or frosted transparent media. The clear area may be frosted but will allow viewing of the dial pointer.

  •

  • High Quality stiff paper - these are made to be to glued or riveted to the metal backed painted dials as were the originals.





>> return



















The original Admiral Channel number scale was a piece of thin plastic that was friction fitted into inserts on the channel sector area. The originals were made of a type plastic that deteriorated and most are now badly damaged or distorted. My replica is made of thin vinyl material with self  adhesive backing. The original scale must be removed along with the metal inserts that the original scale plugged into. Then after cleaning the area, the overlay applied.

return





















return to previous page
